CD12RLP-FD · SHALLOW DRAIN, ENGINEERED FLOW
Low Profile Round Floor Drain
Tailored for you, from blueprint to flow. When faced with specific vertical limitations, the low profile drain is the perfect solution — flexible T304 or 316 stainless for commercial and industrial environments.
Standard features
- Top plate
- 12" × 12" square or round
- Setting ring
- 12 GA, 2.5" below top plate
- Outlet sizes
- 2" · 3" · 4" · 6" · 8"
- Outlet pipe
- 4" long — Sch 10 or Sch 40
- Sump depth
- 2.5"
- Traffic rating
- Forklift — 10,000 lb per ASME A112.6.3
Features
- Built to last a lifetime
- 1/2" thick stainless top plate (std)
- 12 GA body — seamless spun
- Sanitary, non-corrosive and heat resistant
Drawings & documents
Need a drawing for your submittal? Request a detail drawing →
Pairs well with
P-traps
Cleanouts
Drain basketsProduct specification
CD12RLP-FD12 x 2.5" deep (Shallow Depth or Low Profile), 12 gauge, all type 304 (CF8) stainless steel industrial floor drain with loose set anti-tilt extra-heavy-duty perimeter drainage cover, 1/2" top plate frame, perforated removable bucket basket with lift handle, pre-sloped bottom sump, and pre-pour concrete stabilizing anchor ring.
The perfect choice
Single-source responsibility for drainage products guarantees high quality and satisfaction. Whatever you choose, we are here to help with many decades of experience. Most of our stainless drain designs are tried-and-true workhorses — there is a reason we stock 12" stainless drains, cleanouts, P-traps, hub drains and laterals.
See it assembled
